Hi

I just laid down the Lai Yuan cruiser in 1/700, based on the SS Models resin kit. There's not much info on her, only a few photos. As I plan to build several more of chinese ships from Beiyang ships, lets gather some files here.

Lai Yuan

King Yuan


I have a question - what are the red circled things in the attached picture? They are shown in the side view of the drawing, but not in the top view...


Attachments:
LaiYuen.jpg [ 89.79 KiB | Viewed 4739 times ]

_________________
1/350 Mare Island Navy Yard 1944 - suspended
1/700 Pre-Dreads - Lai Yuan (SS-Models)
Top
 Profile
Reply with quote
PostPosted: Wed Dec 14, 2016 8:39 am
Offline

Joined: Fri Sep 30, 2016 12:45 am
Posts: 54
Drainage? Perhaps you can check Bronco 1/144 Chih Yuen, that "thing" in the red circle is very similar to the structure on the hull.


Attachments:
ChihYuen.jpg [ 26.84 KiB | Viewed 4729 times ]
Top
 Profile
Reply with quote
PostPosted: Wed Dec 14, 2016 4:47 pm
Offline
PetrOs Modellbau
PetrOs Modellbau
User avatar

Joined: Wed Nov 15, 2006 11:58 am
Posts: 1749
Location: Munich, Germany
Ok, thats most likely! Would it be a permanent thing or something rigged only at port?

_________________
1/350 Mare Island Navy Yard 1944 - suspended
1/700 Pre-Dreads - Lai Yuan (SS-Models)


Top
 Profile
Reply with quote
PostPosted: Wed Dec 14, 2016 8:39 pm
Offline

Joined: Fri Sep 30, 2016 12:45 am
Posts: 54
I think it would be permanent


Top
 Profile
Reply with quote
PostPosted: Thu Dec 15, 2016 2:42 am
Offline
PetrOs Modellbau
PetrOs Modellbau
User avatar

Joined: Wed Nov 15, 2006 11:58 am
Posts: 1749
Location: Munich, Germany
Do you eventually have more pics of 1/144 Bronco Chih Yuen? I dont own the kit (even if I sold several in my store), and the photos of her are somehow rare online

_________________
1/350 Mare Island Navy Yard 1944 - suspended
1/700 Pre-Dreads - Lai Yuan (SS-Models)


Top
 Profile
Reply with quote
PostPosted: Fri Dec 16, 2016 8:34 am
Offline

Joined: Fri Sep 30, 2016 12:45 am
Posts: 54
Maybe I can find some. This kit is not very popular. I know someone in China released 1/700 Ji Yuen kit, just let me check its detail first.


Top
 Profile
Reply with quote
PostPosted: Fri Dec 16, 2016 8:58 am
Offline
PetrOs Modellbau
PetrOs Modellbau
User avatar

Joined: Wed Nov 15, 2006 11:58 am
Posts: 1749
Location: Munich, Germany
There's Ji yuan from Sextant models - https://world.taobao.com/item/457432268 ... .81.lSmUaX
I think there's a resin one from SS-Models, too

_________________
1/350 Mare Island Navy Yard 1944 - suspended
1/700 Pre-Dreads - Lai Yuan (SS-Models)


Top
 Profile
Reply with quote
PostPosted: Fri Dec 16, 2016 10:18 am
Offline

Joined: Fri Sep 30, 2016 12:45 am
Posts: 54
Actually it is a plastic model kit. I will check its detail and also get you some 1/144 and 1/350 Chih Yuen pictures this weekend.


Top
 Profile
Reply with quote
PostPosted: Fri Dec 16, 2016 11:22 am
Offline

Joined: Thu May 30, 2013 1:50 pm
Posts: 1980
W.H.min wrote:
Actually it is a plastic model kit. I will check its detail and also get you some 1/144 and 1/350 Chih Yuen pictures this weekend.

Hi WHmin. You have built the 1/144 Bronco Chih Yuen? I have one in my stash. I also built their 1/350 and was impressed by it so I was all excited when I saw the 1/144 release and ordered one. After having checked the parts I felt they could have done a better job in this larger scale. ie; they added no detail on the maindeck bulwark interiors, and the plastic is really thick there; the deck planking run in long strips and have no butt-ends (although they can be cut in); the deck structures could have been separate parts to make painting easier and avoid a lot of masking. I'm sure it will still build into an impressive model, but was slightly disappointed by these shortcuts. What are your opinions on this? :wave_1: I also have the 1/700 S-Models plastic kit - great model; comes with PE and brass barrels!


Top
 Profile
Reply with quote
PostPosted: Wed Dec 21, 2016 10:07 am
Offline
PetrOs Modellbau
PetrOs Modellbau
User avatar

Joined: Wed Nov 15, 2006 11:58 am
Posts: 1749
Location: Munich, Germany
Thanks, I found a great build of Chih Yuen in 1/144 by Erick Navas online, http://ericknavasmodelismonaval.blogspo ... chive.html, and scratch built the drainage pipes using a 0.2 nickel silver rod for the pipe, and CA soaked paper strips for the "clamps"

_________________
1/350 Mare Island Navy Yard 1944 - suspended
1/700 Pre-Dreads - Lai Yuan (SS-Models)


Top
 Profile
Reply with quote
PostPosted: Fri Dec 23, 2016 3:36 am
Offline

Joined: Thu Dec 08, 2011 6:59 am
Posts: 77
Location: Shanghai,China
Attachment:
调整大小 P1050530.JPG
调整大小 P1050530.JPG [ 78.54 KiB | Viewed 4491 times ]

Attachment:
调整大小 P1050531.JPG
调整大小 P1050531.JPG [ 83.21 KiB | Viewed 4491 times ]

Attachment:
调整大小 P1050532.JPG
调整大小 P1050532.JPG [ 90.91 KiB | Viewed 4491 times ]

Attachment:
调整大小 P1050533.JPG
调整大小 P1050533.JPG [ 92.97 KiB | Viewed 4491 times ]

Attachment:
调整大小 P1050534.JPG
调整大小 P1050534.JPG [ 86.66 KiB | Viewed 4491 times ]


Top
 Profile
Reply with quote
PostPosted: Fri Dec 23, 2016 5:01 am
Offline
PetrOs Modellbau
PetrOs Modellbau
User avatar

Joined: Wed Nov 15, 2006 11:58 am
Posts: 1749
Location: Munich, Germany
Some nice looking what ifs! ;)

_________________
1/350 Mare Island Navy Yard 1944 - suspended
1/700 Pre-Dreads - Lai Yuan (SS-Models)


Top
 Profile
Reply with quote
PostPosted: Wed Mar 13, 2019 10:25 pm
Offline

Joined: Wed Mar 13, 2019 9:39 pm
Posts: 1
Location: China
Dear forum members,

a friendly hello from me to all of you and sorry that I reply to an old post.

But I am really interested in the forth photo of the Lai Yuen, posted by PetrOs
in his first post. I added the photo in my post to make it clear.

I would need to know the source of this image and is there a way to send it to me
in a higher resolution?

Thanks a lot.


Attachments:
laiyuansym22.jpg [ 16.46 KiB | Viewed 3772 times ]
Top
 Profile
Reply with quote
PostPosted: Wed Jul 24, 2019 11:43 pm
Offline

Joined: Tue Jun 14, 2005 6:23 am
Posts: 2643
Location: Copenhagen
Here a torpedo cruiser detached to the Beiyang fleet during the First Sino-Japanese War, but originally from the Guangdong Fleet, Guangyi (Kuang Yi):

Guangyi (1/700)

Guangyi fought 125 years ago, on the 25th of July 1894, in the Battle of Pungdo, the first battle of Sino Japanese War.

She is seen above together with the protected cruiser Jiyuan (Tsi Yuen). Guangyi was built in 1/700using the Oceanmoon kit.

_________________


Top
 Profile
Reply with quote
