Hoping some of our resident subject matter experts can help identifying this winch aboard USS Vestal AR-4 and have better photos and/or dimensioned plans of one.


Attachments:
VestalPortBeamWinch.jpg [ 301.68 KiB | Viewed 1976 times ]
VestalDeck1944(Corrected)2.jpg [ 318.09 KiB | Viewed 1976 times ]

_________________
Have fun, Monkey around.

-Steve Larsen

Catalog of over 2000 products for scale modelers, most in 3D-printed gray resin - https://www.model-monkey.com/
Top
 Profile
Reply with quote
PostPosted: Sun Jan 14, 2018 12:50 pm
Offline

Joined: Sat Jan 17, 2009 2:12 pm
Posts: 2285
it is called a yard winch.


Top
 Profile
Reply with quote
 Post subject: Calling all AR fans!
PostPosted: Tue Jun 26, 2018 1:40 pm
Offline

Joined: Tue Nov 01, 2011 10:27 am
Posts: 36
Dear Folks,

I recently obtained drawings for the USS MEDUSA (AR-1) from the National Archives. A fellow modeler wants to build a 1/96 scale, wooden hull. I have created a wireframe for the hull and will eventually have a superstructure in CAD also. If anyone else has any interest, I will be happy to help out.

Sincerely,
Nelson Petteys


Top
 Profile
Reply with quote
 Post subject: Re: Calling all AR fans!
PostPosted: Sat Jun 30, 2018 11:35 pm
Offline
User avatar

Joined: Wed Jan 12, 2005 1:32 am
Posts: 441
Location: Peach State
NelstoneB wrote:
...I recently obtained drawings for the USS MEDUSA (AR-1) from the National Archives...

You found drawings? I had to make my kit from microfilm and selected blowbacks and photos. What year will his model represent?


Top
 Profile
Reply with quote
PostPosted: Fri Nov 30, 2018 10:39 pm
Offline

Joined: Tue Nov 01, 2011 10:27 am
Posts: 36
Pardon me for not responding sooner. The drawings I obtained show her as-commissioned. There were some deckhouses added aft for berthing before Pearl Harbor. Navsource.org has pictures that would help.

Nelson


Top
 Profile
Reply with quote
PostPosted: Tue Mar 19, 2019 5:47 pm
Offline

Joined: Fri Feb 22, 2019 8:21 pm
Posts: 68
Are there plans available anywhere for the Vestal? I'd like to do one up in CAD to print with my 1/1200 AZ.

_________________
Michael

Love building and CAD modeling WWII Capital Ships

1/1200 Battle of Hampton Roads diorama in progress
1/1200 1945 USS Pennsylvania CAD model in progress


Top
 Profile
Reply with quote
PostPosted: Thu Sep 05, 2019 3:49 pm
Offline

Joined: Mon Jan 07, 2008 10:15 pm
Posts: 639
Judging by the lack of activity in this forum I have a feeling I won’t find an answer to the following question but it’s worth a shot.
I’m trying to figure out what decks on Vestal were wood covered on 12/7/41. I know that by this photo http://www.navsource.org/archives/09/25/09250430.jpg the forward deck had wood but what about the other decks? The photo of her stern that Steve posted above suggests that her stern did not have wood but that pic is also later in the war.
I’m also struggling with whether or not her wood decks were still unpainted at the time of attack. We know for sure that Nevada, Tennessee, Helena had painted decks as part of an experiment but nothing on any other ship has been discovered yet. I’m leaning towards unpainted for Vestal.
TIA


Top
 Profile
Reply with quote
PostPosted: Fri Sep 06, 2019 8:48 pm
Offline
User avatar

Joined: Wed Jan 12, 2005 1:32 am
Posts: 441
Location: Peach State
Based on the plans, all the main weather decks were planked. The Bomb Damage Report even mentions the penetration of 3-1/2" of wood on the fo'c'sle.

Deck color is inconclusive. If you look closely at the picture in the following link, it almost looks like forward of the bridge is unpainted wood, the center is something a little darker and the stern could be painted metal. I have no idea what's right, but I lean toward faded MS.1 with unpainted decks. Maybe John Snyder has more info.

https://visitpearlharbor.org/wp-content ... -Photo.jpg


Top
 Profile
Reply with quote
PostPosted: Sun Sep 08, 2019 9:32 am
Offline

Joined: Mon Jan 07, 2008 10:15 pm
Posts: 639
Mike C wrote:
If you look closely at the picture in the following link, it almost looks like forward of the bridge is unpainted wood, the center is something a little darker and the stern could be painted metal.


Initially I thought the same thing about her forward deck looking lighter than the rest of the ship but we have to keep in mind that she had an awning on the bow that extended back to the elevated gun tub. That explains THAT portion of the deck being light. Right after the gun tub, this picture captured the smoke from the bomb that just exploded on the bow (blue dot shows where bomb hit) so I think we are seeing smoke there, not the deck for the most part.


Top
 Profile
Reply with quote
