Thanks Dan,I have all the parts,trying to find out sizes and placements on the ship

I have a question about Akagi and Kaga in their 3-deck configuration. It looks like the navigation bridge is directly under the forward end of the upper flight deck, between the 8" twin mounts. Does this block aircraft access from the upper hangar to the middle flight deck? I know the middle flight deck was short and of limited use, but was it made inaccessible by design or was this bridge built later? Or does the bridge move or open in some way?

_________________
Vlad

In that configuration, up forward, there is a lower flight deck, a bridge deck, and an upper flight deck. The upper hangar deck is the same level as the bridge deck. So, no flight ops off that deck. The forward lift divides the space between the bridge and the hangar deck.

So was there never a configuration where the middle flight deck was usable for flight ops? Did they decide it wouldn't be useful while the ships were still under construction?

_________________
Vlad

No, never such a configuration. I think it would have been unworkable, given the need for a sizable bridge and the heavy turret armament.

Thanks, shame really I was looking into building one of these and I thought it would be cool to have a plane launching at every level. Not that it really diminishes the awesomeness of their appearance.

_________________
Vlad

It will look cool no matter what

Is their a replacement set for the twin 12cm guns available for the Akagi?
I want to built the Irako and perhaps an Ukuru Escort and they had the same gun.
But the pitroad gun is more than basic and fivestar only made a set for the single gun.

Greetings Christian

_________________
At work:

115 Years of the Battle of the Yellow Sea, 1/700 IJN Matsushima and Hashidate 1904
1/700 ICM SMS König 1916
1/700 Flyhawk HMS Penelope 1939
1/700 Fujimi IJN Shokaku 1941
1/700 Fujimi IJN Nagato 1941
1/700 Aoshima IJN Hayasui 1944

I don't know of any others. It's possible that there may be a 3D printed version available somewhere.

Have you tried these guys?
http://master-model.pl/

_________________
Gerry

Building: Nichimo 1/200 Yamato 1942, Tamiya New 1/350 Yamato 1945

Thanks Gerry, new barrels will help.
But I was thinking of a complete replacement.

Ok thanks Dan,
it looks I need to make a good old scratchbuild to enhance the guns

Greetings Christian

_________________
At work:

115 Years of the Battle of the Yellow Sea, 1/700 IJN Matsushima and Hashidate 1904
1/700 ICM SMS König 1916
1/700 Flyhawk HMS Penelope 1939
1/700 Fujimi IJN Shokaku 1941
1/700 Fujimi IJN Nagato 1941
1/700 Aoshima IJN Hayasui 1944

This is my first post on this or any other modeling forum, so pardon me if I don't observe the protocols.

I am working on 1/350 Akagi by Hasegawa. The plan is to finish her as she was at Midway. My problem is that I purchased
the Hasegawa wooden deck, and I have never used one. So, I have two questions:

1. Is there an appropriate finish/varnish for the deck? What I have seen online isn't very clear about what works best if
anything.

2. The deck came with "stickers" to sub for the waterslide decals in the kit. However, they seem way too bright for the scale, not to mention a ship that had been continuously at sea. Does anybody have ideas on how to weather them? Or would I be better off just using them as stencils and painting them in?

Thanks very much in advance.

Hmm, no one chimed in? I don't use wooden decks, so I'm no help here. This question comes up often enough, yet I don't see a FAQ or helpful hint on it.

Might I suggest a new posting on the main page, with a more generic title such Wooden Deck Questions or something like that.

Thanks. I found a thread over at FineScale Modeler that said the whole thing is a bad idea, but trying to finish a wood deck is almost futile.

Hi Wayne,

I used a wooden deck in 1/700 scale on a Essex class carrier and the 1/700 Akagi. I learned that due to all the deck area and the extreme camber that the Akagi had, it will want to warp and twist unless you apply constant equal pressure when applying it. I wondered to even go so far as to vacuum bag my next attempt.

You need to apply a sanding sealer to the wood before you attempt any painting. I prefered to use wood stains for the overall deck color, followed with very light sanding, and then applied sanding sealer. Make sure your deck is fully secured to the plastic kit deck and the adhesive is fully cured, otherwise you may get some pop ups and warpage. I used Minwax stains and sealer.

For deck markings, you probably don't want to hear this, but masking them out and painting them is the best way. As I found out on my 1/700 Akagi, it turned out to be easier than dealing with all those long decals and trying to line everything up and then find out the decal color was the wrong contrast. The final look is worth the time of masking and painting.

Finish the deck with maybe a light wash of light gray to blend and tone everything down and a final coat of flat clear to seal everything.

Scott

Hi all I'm new here! Just wanted to ask if anyone has a recommendation for sandbags that are good to use for a 1/700 scale Akagi (Single flight deck ver.) Would also be helpful if you could recommend me some IJN 1/700 sailors to get! Thanks all in advance.

Shelf Oddity provides both sailors and ropes/mantlets. Scroll thru: https://shelfoddity.com/index.php?route ... path=20_66

I just watched the recent Bruce Willis movie "Air Raid/Air Strike," where he stars as a US military advisor for the Nationalist Chinese Air Force fighting the Japanese over China just prior to WW2.

In one scene, I saw what appears to be the aircraft carrier Kaga and an IJN task group in the South China Sea/Gulf of Tonkin launching planes to strike Chongqing, China. Here are screen grabs:




Only Kaga or Soryu had starboard islands among the Kido Butai carriers that were active in striking China before Pearl Harbor. The bridge in the 2nd pic doesn't appear to be Kaga, although that could be just lack of effort in CGI-modelling. I am guessing it is more likely Kaga rather than Soryu because of how the carrier hull proportions look.

Some might say that the inclusion of the carrier in the film may just be attributed to artistic license, aside from the inclusion of A6M2 Zeroes that supposedly never went as far as Chongqing, historically.

_________________
"Haijun" means "navy" in Mandarin Chinese.

"You have enemies? Good. It means you stood up for something in your life."- Winston Churchill

Well, at least it's roughly date appropriate, and not a Shinano. Somebody had at least a small inkling.

Oh! COOL!

This is on Amazon Prime. Which I have.
